Longan Peeling Machine
Longan peeling machine
Longan peeling process
Litchi and Longan Peeling Machine can peel off rind of litchi(longan) without twig. It widely applies to produce Longan juice, Longan wine, preserved fruits, dry pulp, canned food of litchi(longan).The machine features compact and efficient, less consumption of energy, what's more, the peeled Longan is clean and loss of pulp is very small.
Department of Agriculture of Guangdong Province and Department of Science and Technology of Guangdong Province (Guangdong is the largest origin of Chinese Longan) identify and prove the technical performance of Litchi and Longan Peeling Machine is lead in China and in the world. Additionally, we have hold two patents on the machine.
|Longan Peeling Machine||XLL-G3000|
|capacity||3000kg/h(for Longan)/2000kg/h(for longan)|
|Packing size (mm)||1700*1450*1800|
|Efficiency for peeling(peeling rate)||Above 90% for graded fruits, about 85% for ungraded fruits|
Longan Peeling Machine Working Principle
After getting rid of the twigs and impurities from Longan(or longan) ,cleaning rinds with water and disinfection, and simple classification according to size, feed Longan to oriented strip and rotary rubber wheel which is driven by three power rollers. Along with rotation of rotary rubber wheel, feeding wheel pushes Longan to the surface of oriented strip to cut by knife fixed on knife shelf one by one. Longan pump with pit would be separated from rind by separating wheel, and falls into vibratory output launder. At last, output wheel for rind takes the rind out of machine.
Flowchar of Complete Set of Lychee Peeling Line
L30m * W2m * H2.5m
(set up in straight line)
|Labor required||About 10 workers|
|Floor space can be adjusted according to customer’s workshop space.|
